Tripod Turnstile

• Alarm
• Audible Alarm for Unauthorized Access

• Connectivity Type
• RS232/RS485, TCP/IP (Optional)

• Control System
• Microprocessor based Control Board

• Dimension (L*W*H)
• 480 x 280 x 980 mm

• Display Type
• LED Direction Indicator

• Features
• Compact Slim Design, Unidirectional Passage, Anti-tailgating, Emergency Override

• Material
• Brushed Stainless Steel (304 Grade)

• Mounting Type
• Floor Mounted

• Power Consumption
• 30W

• Power Supply
• AC 220V / 110V, 50/60Hz

• Sensor Type
• Infrared Sensor for Passage Detection

• Software Detail
• Compatible with Access Control Software (Optional)

• Technology
• EM RFID (Unidirectional Passage)

• Usage & Applications
• Entry/Exit Management in Offices, Metro Stations, Airports, Factories, etc.

• Voltage
• AC 220V 10%, 50Hz

• Weight
• Approx. 45 Kg

• Alarm
• Unauthorized Entry Alarm

• Connectivity Type
• RS485, Dry Contact Input

• Control System
• Microprocessor Based

• Dimension (L*W*H)
• 480mm x 280mm x 980mm

• Display Type
• LED Indicator for Direction

• Features
• Compact Design, Both Side Operation, High Durability, Unidirectional/ Both Sides

• Material
• Stainless Steel

• Mounting Type
• Floor Mounted

• Power Consumption
• Less than 70W

• Power Supply
• Integrated AC Power

• Sensor Type
• Infrared Sensor (Optional)

• Software Detail
• Compatible with Access Control Systems

• Technology
• Electromechanical

• Usage & Applications
• Entry/Exit Control in Offices, Factories, Stadiums

• Voltage
• AC 220V/110V, 50/60Hz

• Weight
• Approx 35 Kg

• Alarm
• Unauthorized passage alarm

• Connectivity Type
• RS485, Relay

• Control System
• Remote control/Access card integration

• Dimension (L*W*H)
• 1200mm 280mm 980mm

• Display Type
• LED indicators

• Features
• Bi-directional control, Anti-tailgating, Automatic reset, RFID EM Card compatible, Durable and slim design

• Material
• Stainless Steel SUS304

• Mounting Type
• Floor Mounted

• Power Consumption
• Approx. 60W

• Power Supply
• Internal SMPS

• Sensor Type
• Infrared Sensor

• Software Detail
• Compatible with EM Card management software

• Technology
• Microprocessor based controlling system

• Usage & Applications
• Access Control in offices, factories, metro stations, airports, stadiums

• Voltage
• AC 100-240V, 50/60Hz

• Weight
• Approx. 50 kg

• Alarm
• Audible and visual over-ride, illegal access alarm

• Connectivity Type
• RS485, Dry Contact, TCP/IP (optional)

• Control System
• Microprocessor based controller

• Dimension (L*W*H)
• 480 x 280 x 980 mm

• Display Type
• LED Direction Indicator

• Features
• Bi-directional operation, Anti-tailgating, Emergency release, High throughput, Durable design

• Material
• Stainless steel (Grade 304)

• Mounting Type
• Floor mounted

• Power Consumption
• 60W maximum

• Power Supply
• AC power supply

• Sensor Type
• Infrared sensor (for access and anti-tailgating)

• Software Detail
• Compatible with standard access control software

• Technology
• Electro-mechanical, motorized mechanism

• Usage & Applications
• Office buildings, metro stations, factories, stadiums, etc.

• Voltage
• AC 220V 10%, 50Hz

• Weight
• 45 kg

• Alarm
• Audible and Visual Alarm for Unauthorized Access

• Connectivity Type
• RS232/RS485, TCP/IP (optional)

• Control System
• Microprocessor Based Controller

• Dimension (L*W*H)
• 480 x 280 x 980 mm

• Display Type
• LED Indicator

• Features
• Bi-directional Passage, Anti-Tailgating, Automatic Reset, Durable Construction

• Material
• 304 Stainless Steel

• Mounting Type
• Floor Mounted

• Power Consumption
• 60W (max)

• Power Supply
• AC 220V 10%, 50Hz

• Sensor Type
• Infrared Sensor

• Software Detail
• Compatible with third-party access control software

• Technology
• EM Card (RFID) Access Control

• Usage & Applications
• Access control in offices, factories, stations, administrative buildings, etc.

• Voltage
• AC 220V 10%, 50Hz

• Weight
• Approx. 38 kg

• Alarm
• Audible & Visual Alarm for Invalid Entry

• Connectivity Type
• RS485, Relay, TCP/IP (optional)

• Control System
• Access Control Integration

• Dimension (L*W*H)
• 420 x 330 x 980 mm

• Display Type
• LED Indicator

• Features
• Slim Design, Bi-directional, Anti-tailgating, Fast Unlocking, Easy Maintenance

• Material
• 304 Stainless Steel

• Mounting Type
• Floor Mounted

• Power Consumption
• 60W max

• Power Supply
• AC Power Supply

• Sensor Type
• Infrared Sensor

• Software Detail
• Supports third-party access control software

• Technology
• Motorized Tripod Turnstile

• Usage & Applications
• Entry and Exit Control for Office, Metro Station, Buildings, Factory

• Voltage
• AC 100-240V, 50/60Hz

• Weight
• ~45 kg
